The new industrial door operator system from Novoferm is based on DC technology and combines the advantages of different operator and control types into a particularly advantageous solution:
Existing drives can be easily replaced by this new model
Soft start and soft stop
Self-learning force detection
Adjustable speed profiles
Speed comparable to 400 Volt AC systems
Connection possibilities for all kinds of accessories
Three emergency operations (emergency hand chain, emergency hand crank and quick release)
For gates up to 10,5 m2 no closing edge safety device, slack rope switch or spiral cable necessary
The range of application of the DCC 80 includes all sectional door types (40/ 60/ 80 mm) and also all common types of fittings. Maximum door weight is 260 kg for a balanced door with torsion springs. The DCC 80 is particularly suitable for smaller sectional doors up to a size of approx. 3,250 x 3,250 mm.
These doors can be operated most conveniently without additional safety devices – which also significantly reduces the installation time of the DCC 80 compared to conventional drive systems.
Speeds up to 30 r/m
230 Volt 1-phase connection
24 Volt battery backup connectable
Additional end position and connection board (optional)
Prioritized opening (function like RWA)
Traffic light connection available
Operation for gates with wicket door
Electromechanical door lock can be connected (EDL 100)
Maintenance cycles adjustable
Error history via app (last 10 errors)
Ready for online monitoring
As a further highlight of the new drive system, the new operating unit is available in two variants. The IPD-S is an intelligent 3-fold pushbutton with LED illuminated buttons, connection options for accessories such as light barriers, spiral cables, etc. and has a digital display as well as a communication line directly to the motor/ gear unit with control.
The new DCC 80 with its operating unit is also integrated as a combination into the new generation of I-Vision 5 dock leveller controls to achieve even greater advantages in the equipment of dock leveller systems. The resulting new combination control system is, for example, our I-Vision 5 XD.
Programming and setting can be done either via the optional Bluetooth dongle with the “Easy Set Up & Service App” or conventionally via the buttons on the control unit. Together with the optional BLE dongle, an integrated BLE mesh system and the IoT gateway, the DCC 80 forms the optimal basis for your service. The data is transmitted directly to our online monitoring system. So you are always informed about the gate system.
