This makes installation of the NovoPorta Premio even easier: The multifunctional mounting element in the basic corner frame sets standards for different installation methods when installing in all common wall types. The further improved rebate bolting method saves a lot of time and optimizes the number of fasteners as well as the variance of frame backfi llings. The new installation method once again signifi cantly expands the application and assembly possibilities of the Premio standard frame.
IHRE VORTEILE IM ÜBERBLICK:
Improved support effect to the wall due to new punching in the corner frame, which sits 8 mm deeper than before in the frame rebate
Installation in concrete walls: Reduced risk of hitting the reinforcement
The rebate mounting adapter with revised spacer plate geometry prevents the frame from twisting even more reliably
Cover caps in rectangular format for even better hold
Premio EI 30: Installation now also in aerated concrete walls possible with rebate screw mounting
With mortared frame, 100 mm standard dowel length can be used for installation in masonry
2-leaf doors (up to CS (= coordinating size) 3,000 x 2,125 mm): Reduction of frame fixing points on vertical frame stiles from 10 to 8
FOR INSTALLATION AT GREATER INSTALLATION HEIGHTS AND FOR RAISED FLOORS
Novoferm continues to expand the platform concept in the commercial hinged door segment. With a size extension of the proven thick rebate steel hinged door series NovoPorta Premio, all fire protection classes up to EI 90 are now also available in oversizes.
This extends the range of applications, as these doors are now also approved for installation at greater heights.
This means that special versions are available for installation in particularly high wall openings, for installation in raised installation positions (plinth > 500 mm) and for installation on raised floors (e.g. in data centers).
1-leaf and 2-leaf Premio EI 30 and EI 90 GE oversizes up to CS (= coordinating size) 1,500 x 3,000 mm and BRM 3,000 x 3,000 mm
FOR COMPARISON PREVIOUS DIMENSIONS:
1-leaf CS (= coordinating size) up to max. 1,375 x 2,500 mm
2-leaf up to max. 2-leaf CS (= coordinating size) 2,500 x 2,500 mm
WITH FACTORY-FITTED BACKFILLING WITH GYPSUM PLASTERBOARD STRIPS
Novoferm supplies factory-filled finished shape block frames with gypsum plasterboard strips, which saves the installer the extremely time-consuming backfilling on the construction site – according to the motto “screw it, that‘s it”!
And best of all: The block frames are EI 90 suitable and have burglary protection up to RC 3.
Finished shape block frames for Premio construction types EI 90 (previously EI 60)
With factory filled gypsum plasterboard strips certified for fire protection EI 90 and also for all RC 3 door models for internal use
Standard widths to match the thinnest approved wall (external dimension 100 mm up to EI 60 and external dimension 140 mm up to EI 90)
Block frame variant type 1.1 for MZ and EI 30 with reduced recess available (larger clear passage at the frame)
Factory-screwed dowel plate
Precisely fitting and stable miter corner connector shoes
Screwed-on extension profiles without weld deformation
Additional extension profiles width 25 mm available
The high-quality Novoferm opening limiter provides controlled support for the opening function from approx. 75 ° opening by means of an integrated gas pressure spring and fixes reliably the opened door in position.
Adjustable opening angle and end stop up to max. approx. 103 °
Flat design, silver color similar to RAL 9006
Protection of door leaf and wall system behind the door
No floor door stop required and therefore no risk of tripping
Easy retrofitting possible
Suitable for multi purpose doors (MZ) up to 120 kg door leaf weight
The sliding door system NovoSlide Pocket fits seamlessly into the wall. It is suitable for all frame variants (Novoferm steel frames, wooden frames on site or frameless with Novoferm gypsum reveal), can be combined with glass or wooden door panels provided by the customer, has double damping as standard and impresses with these transport advantages:
Transport disassembled box for easy transport to and on the construction site
Very stable when assembled and thus safe to carry on the construction site to the installation point
In buildings such as hotels, schools, administrations or hospitals, there is a great demand for steel frames for wooden doors which meet the respective requirements for fire, smoke, burglary or sound protection. Novoferm offers suitable frames with a very wide range of different profi le geometries. Naturally also individually adapted to customerspecific profile shapes and equipment variants (hinges, door closers, electric strikes, cable transitions, magnetic contacts, strike plates, multipoint locks, escape door strikes or various transom fillings, etc.).
In this combination, visually appealing, durable and technically very high-quality door systems can be realized, completely individual according to customer requirements.
