Premium plus sectional garage doors made of steel


1) For private garages up to 5500 mm width
Premium Plus sectional garage doors are ideal for private garages and double garages up to a width of 5.50 m in new builds and renovations.

2) Große Auswahl an endbeschichteten Oberflächen und Farben
Premium Plus sectional garage doors with paint finishes, wood effects and our satin surfaces are top coated. As well as giving your garage an elegant look, our quality surfaces are more resistant to environmental factors.

3) Double skinned and insulated
Our steel sections are exclusively manufactured in a double-skinned sandwich construction and filled with an insulating rigid PUR foam core. With a thickness of ≈67 mm (insulation performance U(p) = 0.34 W/m²K), this core ensures superb thermal and acoustic insulation.

4) Triple-glazed windows
Also available with triple-glazed window variants that provide not only excellent heat insulation, but also outstanding light permeability.

5) Double floor seal
The double floor seal on the bottom edge of the door guarantees the best possible protection from water and dirt while smoothing out any slight unevenness in the floor. It also reduces heat loss.

6) Anti-pinch protection inside and out
The special design of the sections and hinges prevents
pinching on the door leaf from the outset. Pinching is not a risk on the inside of Novoferm doors, either.

7) Thermo frame set
The optional sealing and insulating strip system improves the heat insulation by up to 15 %* by optimising the frame along three sides when mounted behind the opening and actively contributes to optimising the entire building’s performance balance.


* Performance dependent on door pattern and size.


1) Uniform appearance of inside of door
A highlight of the Premium Plus door is the uniform appearance of the inside of the door. The elegantly smooth “Noblesse” finish on the door leaf and the hinges and profiles in traffic white (similar to RAL 9016) enhance its harmonious overall look.

2) Thermal breaks
The patented thermally broken sections, with PUR rigid foam core and additional seal between the sections, deliver an EXTRA PLUS of insulation.

3) Stainless steel ball-bearing tandem rollers
High-quality, ball-bearing tandem rollers in stainless steel ensure extremely smooth and even door travel.

4) Optional spring technology
Smaller sizes of the Premium Plus sectional garage door can optionally be equipped with multiple safety tension spring assemblies or torsion springs. The vertical tension springs require less installation depth (in combination with a low header) and open up new possibilities when space is limited. On larger sizes, the door is equipped with torsion springs, either front or rear mounted.

5) NovoPort^® –  unique and flexible
The NovoPort^® patented operator system has an integrated wall switch and door status display on the remote control to increase ease of use. The innovative, flexible side installation, either right or left, rules out any installation problems from the outset, and leaves the ceiling free.

6) “Easy” safety opto sensors
The supplementary “Easy” safety opto sensors reliably detect people and obstacles and stop the closing process if there is any doubt.

Our premium plus sectional garage doors with 70 mm insulation are available on request in a elegantly smooth Noblesse surface finish that repels dust and moisture. For further individualization, you can choose from 14 top-coated, attractively priced Super Colors/preferred colours and nearly all RAL colours.

You’ve already envisaged a garage door with a certain pattern and colour, but it’s still not individual enough for you? Then take a look at our attractive glazing variants. They not only make a feature of your garage, but also let the light in as well. And that’s especially appealing if you also use your garage as a hobby room or workshop. All Novoferm glazing panels are made of weather-resistant acrylic glass or impact-resistant polycarbonate and offer outstanding light permeability.


Dimensions:
inside:  approx. 392 x 192 mm
outside: approx. 460 x 260 mm

Window thicknesses:

• Large rib pattern: 16 mm double acrylic glazing, transparent or crystal


* Only for large rib and flush garage door patterns.
